  • CNC Machining or Not: Not CNC Machining
  • Type: Etching / Chemical Machining, Rapid Prototyping
  • Material Capabilities: Aluminum, Brass, Precious Metals, Stainless Steel
  • Micro Machining or Not: Not Micro Machining
  • Place of Origin: Guangdong, China (Mainland)
  • Model Number: SG153202
  • Brand Name: Sinoguide
  • Name: Photo Chemical Etching Precision Parts
  • Thickness: 0.03mm-1.5mm
  • Tolerance: +/-0.01mm
  • Size:: 1*1mm2 - 300*500mm2
  • Smallest Open Hole: 0.1mm
  • 0.1mm: +/-0.025mm
  • Edge: Burr free
  • Artwork:: Ai/Coreldraw/PDF etc
  • MOQ:: 2500PCS
  • Supply Ability: 60000pcs/day

Packaging & Delivery

Packaging Details SinoGuide Packing or Customized
Delivery Time 2~6 working days
Product Description



Photo Etching Precision Parts

SinoGuide specializes in the manufacture of precision light gauge metal parts from .0005" thick and up. The photo etching process (also called photo chemical etching and photo chemical milling) allows us to produce intricate metal components with close tolerances that are impossible to duplicate by other production methods. Photo etching eliminates the cost of hard tooling, improves design flexibility, and shortens lead times while eliminating burring and stress problems.

Applications:

 The photo etching process (also called photo chemical etching and photo chemical milling) allows us to produce intricate metal components with close tolerances that are impossible to duplicate by other production methods. Photo etching eliminates the cost of hard tooling, improves design flexibility, and shortens lead times while eliminating burring and stress problems.





Product Description

Product name:

Photo Etching Precision Parts

Material:

Stainless steel, copper, silicon steel plate,or customize

Size:

According to customers

Thickness:

0.03-1.5mm is available

Technique:

High precision etching

Hole:

0.01mm(customize)

Spacing

0.018mm(customize)

Hole shape:

Round/ Square

Surface finish:

Clean .no burr

Features:

No burrs,No broken point,no plugging holes

Application:

Fiber filter,Textile machines or customize

Certificate:

RoHS,ISO

Inspection:

Two-dimension inspection machine,magnifier

Other Related Items

Price:

According to product specification

Sample Offer:

Within 3-6 days

Payment:

T/T,L/C,Paypal,Western Union

Lead time for mass production:

Within 6-10 days after payment

Production ability:

10000pcs/week

Metal process methods available:

Stamping,Chemical etching,Laser cutting

Acceptable file format:

DWG,DXF,IGES,PDF,JEPG

Standard met:

Customer specification,2D CAD drawing









 Advantages of Photo Etching:

•Low tooling cost, no need for expensive DIE/Mould
•Can fabricate more thinner metals(T=0.02-1.2 mm)
•No alteration process, the characteristics can be obtained as the designer intended
•High accuracy
•Various apertures, shapes and bar combinations
•Burr & Stress free manufacturing method
•Prototypes – fast turnaround to meet your needs
•High volume capabilities


SinoGuide provides high quality and performance photo etching components for customers, further more, our high production capacity can also fulfill your high-volume orders and shorten the lead time.

SinoGuide is also a one-stop solution provider, we can also provide you value added service such plating, polishing, stamping, PVD coating etc.





Below info will be helpful for your etching project



High Precision Photochemical Etching Design Guide



High Precision Photochemical Etching EDGE BEVEL Design Guide



High Precision Photo chemical Etching Thru Hole Design Guide



Etching Stainless Steel Check List
